ZLL SG918 RC Car 4WD Brushless 70km/h High Speed 1∶16 Full Scale Drift Car

ZLL SG918 RC Car 4WD Carbon Brush 70km/h High Speed 1∶16 Full Scale Drift Car

Brand: ZLL
Product name: SG918 MAX (Brushless) / SG918 PRO (Carbon Brush)
Color: Orange and blue (Gulf Oil color) / White
Material: Hardware; Electronics; Plastic
Differential structure: SG918 MAX: Planetary gear differential (metal); SG918 PRO: Planetary gear differential (nylon)
Motor: SG918 MAX: 2440 brushless motor (4500 KV value); SG918 PRO: RC390 high-speed carbon brush strong magnet (magnetic protection + heat sink)
ESC/Receiver: SG918 MAX: 35A 2S integrated control (splashproof); SG918 PRO: 30A 2S integrated control (splashproof)
Servo: SG918 MAX: three-wire 17G digital servo; SG918 PRO: 5-wire 17g
Body battery: 7.4V 1300mAH 10C Lithium-ion battery (T plug)
Remote control battery: 3 "AA" (not included)
Charger: USB cable charger
Frequency: 2.4GHz (supports multiple cars competing in the same field)
Remote control distance: ≥150 meters
Remote control category: full-proportional synchronous control system (gun control)
Control time: about 30 minutes
Charging time: 3-3.5 hours (USB balance charge)
Wheelbase parameters: wheelbase: 185mm; wheelbase: 188mm; wheel diameter: 85mm
Speed: SG918MAX Brushles: 70 km/h (maximum speed); SG918PRO Carbon Brush: 40 km/h (maximum speed)
Protection function: charging protection, stuck protection, high temperature protection, low voltage protection
Headlight configuration: demon angel eye headlights (seven modes), warning lights, taillights
Body weight: SG918 MAX: 920g; SG918 PRO: 890g
Packaging weight: 1.75 KG
Color box specifications: 37.5*14.5*25 CM
Product size: 39*15*10CM

SG918 MAX product function configuration:
1. ZLL SG918 MAX adopts simulation structure design, has the control feeling of real car, realizes full-proportional stepless speed change, high-speed driving, sudden acceleration, deceleration, braking, reversing, left turn, right turn;
2. Applicable sites: flat land, sand, mud, grass.
3. ZLL SG918 MAX adopts four-wheel drive: front and rear upright spring shock absorbers, double wishbone independent suspension system;
4. 2.4G full-proportional synchronous remote control system. Full-proportional throttle/steering;
5. ZLL SG918 MAX adopts metal differential, metal differential cup, powder planetary gear, powder driving gear, powder main gear;
6. ZLL SG918 MAX adopts metal CVD front drive shaft, metal rear dog bone, metal wheel cup;
7. Three-wire 17G digital servo;
8. Super battery power: 7.4V, 18650-1300mAh Li-ion battery (T plug), discharge rate 10C;
9. New remote control panel function, rudder volume adjustment;
10. ZLL SG918 MAX adopts 16 ball bearings throughout the vehicle;
11. Metal second floor plate, metal front and rear arm code, metal middle drive shaft;
12. ZLL SG918 MAX The car body is made of high-toughness explosion-proof PVC car body;
13. Equipped with LED headlights; (three gear modes: always on, slow flash, fast flash);
14. Simulated sports car vacuum tires, strong grip
15. ZLL SG918 MAX is equipped with a set of spare drift wheels (4 pieces) for players to enjoy the fun of drifting;
16. ZLL SG918 MAX Demon Angel Eye seven-mode function: Demon Angel Eye Flowing Light, Demon Angel Eye Always On, Demon Eye Always On, Angel Eye Always On, Demon Flowing Light, Demon Angel Eye Breathing Light, Turn Signal (Flashing Front and Back)

SG918 PRO product function configuration:
1. ZLL SG918 PRO adopts simulation structure design, has the control feeling of a real car, realizes full-proportion stepless speed change, high-speed driving, sudden acceleration, deceleration, braking, reversing, left turn, right turn;
2. Applicable venues: flat land, sand, mud, grass.
3. ZLL SG918 PRO adopts four-wheel drive: front and rear upright spring shock absorbers, double wishbone independent suspension system;
4. 2.4G full-proportional synchronous remote control system. Full-proportional throttle/steering;
5. 2.4G splash-proof four-way 30A integrated electric adjustment/receiver;
6. Front wheel cross ball head universal joint drive shaft, rear wheel split dog bone drive shaft;
7. Five-wire 17G servo;
8. Super battery power: 7.4V, 18650-1300mAh Li-ion battery (T plug), discharge rate 10C;
9. The whole car uses 16 ball bearings;
10. ZLL SG918 PRO uses metal second floor, metal front and rear arm code, metal middle drive shaft;
11. The car shell uses high-toughness explosion-proof PVC car shell;
12. Equipped with LED headlights; (three gear modes: always on, slow flash, fast flash);
13. ZLL SG918 PRO is equipped with a set of spare drift wheels (4 pieces) for players to enjoy the fun of drifting;
14. Simulation of sports car vacuum tires, strong grip;
15. ZLL SG918 PRO adopts seven modes of demon angel eyes: demon angel eyes flowing lights, demon angel eyes always on, demon eyes always on, angel eyes always on, demon flowing lights, demon angel eyes breathing lights, turn signals (front and rear flashing at the same time)

Packing list:
1. Complete vehicle; 2. Remote control; 3. Product English manual; 4. Lithium battery; 5. USB charger; 6. Drift wheel; 7. Shock absorber adjustment buckle; 8. Metal pin; 9. Phillips screwdriver; 10. Hexagonal socket;

Precautions:
1: Charging protection: constant current and constant voltage balanced charging, protection against battery overcharge and overcurrent.
2: Motor anti-stuck protection: When overloaded, the motor stops working.
3: High temperature protection: When the working temperature is higher than the set temperature, the drive control circuit stops working and resumes working after the temperature drops to a safe value.
4: The low voltage power-off function of the electric adjustment, when the battery is lower than about 6.3-6.4V, the power will be automatically cut off to prevent the battery from being damaged by over-discharge.
